1200W Micro Solar Panel Smart Inverter Pure Sine Wave MPPT Grid Tie

Description An inverter can efficiently turn the direct current generated by solar panels into the alternating current used by household appliances. This micro inverter makes it easier. Made of fine aluminum alloy, this IP65 waterproof inverter has a wide range of functions, good safety, convenient installation, and high-cost performance. We believe this inverter will not disappoint you.
1200W Micro Solar Panel Smart Inverter Pure Sine Wave MPPT Grid Tie Inversor New Notes Please install the inverter correctly according to the instructions. If you have any questions, please contact the relevant personnel. Please don't dismantle the machine. Only qualified maintenance personnel can repair the inverter. Please install the inverter in a place with low humidity and good ventilation to avoid overheating the inverter and remove the surrounding inflammable and explosives. When using this inverter, please take good care of your children to prevent them from touching and playing to avoid electric shock. Please note that our products are grid-connected, the AC output port has to be connected to the home grid in order to achieve grid-connected power generation. When the input load is with solar panels, it is important that the VOC voltage is between 30-48V. We recommend that the solar panel is configured for 20% more power than the power of the product. For example, if the product is 600W, the total power of the solar panels should be between 700-750W. When the input load is a battery, we recommend a battery voltage of 36V, which can be connected in series with 3 12V batteries. Please note that the positive and negative polarity should not be reversed when connecting the product. The recommended battery current is 36V/10mah for 300W, 36V/20mah for 600W, and 36V/40-45mah for 1200W. The input and output voltage of the configuration is within the normal operating voltage range of the product in order for the product to work properly and achieve grid-connected power generation. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement. Please make sure you do not mind before you order. Description An inverter can efficiently turn the direct current generated by solar panels into the alternating current used by household appliances. This micro inverter makes it easier. Made of fine aluminum alloy, this IP65 waterproof inverter has a wide range of functions, good safety, convenient installation, and high-cost performance. We believe this inverter will not disappoint you. Key Features Premium Material: The inverter is made of aluminum alloy, which is durable, corrosion-resistant, and not easy to rust. You can use it for a long time without frequent replacement, and your cost can be saved. High Efficiency: The inverter has built-in high-precision maximum power point tracking, which can optimize the power collection from the solar panel, accurately capture and lock the maximum output power point, and greatly increase power generation to more than 25%. In addition, the efficient power reverse transmission technology can transmit the power that can not be used up to the grid in the reverse direction to other places for use, and the power transmission rate can reach 99.9%. LCD Display: The inverter is equipped with an LCD display screen to monitor voltage, power, frequency, current, etc. so you can see the machine clearly in operation. Digital Control: The inverter adopts intelligent soft switching technology, high-frequency switching power supply technology, and 32-bit DSP full digital SPWM control technology, making the product strong anti-interference ability, fast operation speed, high intelligence, and a powerful functional system, which can meet the needs of users. Electrical Isolation: The output and input of the system are completely electrically isolated, the insulation performance of the entire power distribution system is good, and the fully isolated booster circuit is safer and more reliable. Safety Guard: The inverter has six protection functions: over-temperature protection, under-voltage alarm, under-voltage protection, over-voltage protection, short circuit protection, overload protection, etc. Besides, the IP65 waterproof design can prevent rain from eroding its surface, so you can use it with confidence. Easy Maintenance: After the installation of the power station, you don't need to do maintenance work. After a long time, you only need to remove the dust on the photovoltaic panel. Small Footprint: W ith a size of 8.27*14.72*1.57inch, the inverter adopts high-frequency telephone, micro processing, and other technologies, so it is smaller, lighter, and won’t occupy too much space. Flexible Installation Mode : During installation, you can stack multiple inverters at will, form a single-phase parallel stacking system, or conveniently form a three-phase system to provide a three-phase AC. Worry-free Service: We have been working hard to provide better service and quality for our customers, which is our goal. If there is any quality problem with our inverters. Please contact us in time. Details Gasket: The inverter is equipped with two gaskets to help you install the photovoltaic support, making th e inverter more stable. Heat Dissipation Holes : The inverter is provided with heat dissipation holes, which can play a good role in heat dissipation and prolong the service life of the inverter. Application This product is applicable to 30V or 36V solar panels, 36V batteries. The inverter can be widely used in residential or commercial areas for turning the direct current generated by solar panels into alternating current. How to Use Step 1: Install the inverter on the support of the photovoltaic panel with the screws provided by the machine. Step 2: Connect the positive and negative poles of the DC connection plug on the photovoltaic panel to the DC input terminal of the inverter. Step 3: Open the waterproof cover of the AC output interface of the inverter and connect the AC cable to the AC waterproof plug. Step 4: Connect the AC output cable to the AC main cable. Step 5: Repeat steps 1 to 3 to install and connect all inverters. Step 6: Connect the AC main cable to the public grid and start your green energy journey Specification ✅Model: WVC-1200W ✅ Color: Silver ✅ Material: Aluminium Alloy ✅ Power: 1200W ✅ Voltage: 110V ✅ Plug Type: US Standard ✅ Maximum Input DC Voltage: 54V ✅ Peak Power Tracking Voltage: 22-45V ✅ Operating Voltage Range: 17-50V ✅ Min/Max Start-up Voltage: 22-50VDC ✅ Maximum DC Short Circuit Current: 80A ✅ Maximum Input Operating Current: 54.4A ✅ Peak Power Output: 1200watt ✅ Rated Output Power: 1150watt ✅ Rated Output Current: 9.58A ✅ Rated Voltage Range: 80-160VAC ✅ Rated Frequency Range: 57-62.5Hz ✅ Power Factor: ＞99％ ✅ Max Unit Per Branch Circut: 3pcs(Single-phase) ✅ Static MPPT Efficiency: 99.5% ✅ Maximum Output Efficiency: 91.2% ✅ Night Time Power Loss: <1W ✅ Total Flow Distortion: <5% ✅ Ambient Temperature Range: ﹣40℃~60℃/﹣40℉~140℉ ✅ Waterproof Rating: IP65 ✅ Cooling Method: Self-cooling ✅ Communication Mode: Power Line Carrier ✅ Power Transmission Mode: Reverse Transmission, Load Priority ✅ Gross Weight: 4.08kg/8.99lbs ✅ Net Weight: 2.88kg/6.35lbs ✅ Product Size: 21*37.4*4cm/8.27*14.72*1.57inch ✅ Package Size: 47.5*34*11.5cm/18.7*13.39*4.53inch Package Included 1* Micro Inverter 1* Power Cord 1* English Manual Other Accessories for Installation Payment Delivery details Terms of sales About us Contact us Payment We accept ebay payment 。 Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Shipping: 2-9 working days to: USA Terms of sales



We maintain high standards of excellence and strive for hundred percent customer satisfaction. Feedback is very important to us. We hope that you contact us immediately before you give neutral or negative feedback, so that we can address your concerns. It is impossible to address issues if we do not know about them!



About us Your satis faction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects.
a) If you receive a defective item, you may return it or ask for a discount. Please contact us within 14 days after you receive the package.
b) What you returned must be intact and in its original packaging as re? u. Customer is responsible for shipping costs of the returned item.
c) We will cover the cost of shipping back t with the shipping rate indicated in the registration page. We will send you a new unit or refund the full payment you paid.
Thank you. Contact us Business Hour Business Hour: Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. Brand TBvechi Feature1 fashion Model 1200W Grid Tie Inverter MPN Does not apply Application Home/Garden Resistance Properties Waterproof Inverter Technology Microinverter Current Type DC System Configuration Grid-Tie Power Source Solar Charging Mode MPPT (Maximum Power Point Tracking) Recommend PV 4*250~300W Rrequency Auto switch 50HZ/60Hz Reccommend PV (Voc) 34~50V DC Type Charger/Inverter Color Silver Power 1200W Voltage 110V Maximum Input DC Voltage 54V Peak Power Tracking Voltage 22-45V Features Corrosion Resistant Operating Voltage Range 17-50V Min/Max Start-up Voltage 22-50VDC Maximum DC Short Circuit Current 80A Maximum Input Operating Current 54.4A Peak Power Output 1200watt Rated Output Power 1150watt Rated Output Current 9.58A Rated Voltage Range 80-160VAC Rated Frequency Range 57-62.5Hz Power Factor ＞99％ Max Unit Per Branch Circut 3pcs(Single-phase) Static MPPT Efficiency 99.5% Maximum Output Efficiency 91.2% Ambient Temperature Range ﹣40℃~60℃/﹣40℉~140℉ Waterproof Rating IP65 Communication Mode Power Line Carrier Power Transmission Mode Reverse Transmission, Load Priority Gross Weight 4.08kg/8.99lbs Net Weight 2.88kg/6.35lbs Product Size 21*37.4*4cm/8.27*14.72*1.57inch Package Size 47.5*34*11.5cm/18.7*13.39*4.53inch Current Output 10 A or Less Current Rating 9.58A

Returns Accepted for this item if it's within 30 Days
